AUTOOL SDT202 SDT206 Smoke Machine Pipe Smog Generator Leakage Detector

From: $168.98

SDT 202
SDT 202
SDT 206
SDT 206
Choose an option
Choose an option
China
Germany
Russia
United States
Clear
SKU MOT232-2/MOT232 Category

Description??

AUTOOL SDT202 and SDT 206 Car Smoke Leak Detector is a professional auto pipe leak detect tool. It will help us position cars motorcycles leakage on the pipe systems quickly and exactly, such as Intake System Test, Exhaust Systems Test, Crankcase system test??Car Sealing Test, Fuel Tank System Test, Turbo System Test??Various Pipe Fittings Test.

How to do leakage test??

1.Fill 20ml baby oil to the detector for the first time. Open the engine cover, and hang the detector in the cover.

2.Disconnect the pipe that needs to be connected with detector.

3.Connect detector with DC12V battery, turn on the power switch, and the detector starts to work.

4. In about 30 seconds, the pipe will be filled with smoke. Check the leak points. Please use head lamp if necessary.

AUTOOL SDT202 and SDT 206 Car Smoke Leak Detector Features??

1.[Wide Range of Applications]: For detecting the leakage of pipe systems on cars, motorcycles, snowmobiles, off-road vehicles, ATVs, light trucks and speedboats boats. Suitable for all car models.

2.[Powerful and Easy to Operate] : The AUTOOL ST202 and SDT 206 has its own Air Pump without relying on other machines and Pressure Gauge with precise scales. Simply connect the detector with the DC12V battery, it can output thick smoke within 30s after turning on.

3.[Advanced Technology]: It works on the EVAP system. (Provided with another version that specially designed for EVAP system). Equipped with flow meters for accurate data display.

4.[Overheat & Anti-frost Protection]: This smoke detector has an intelligent protector, if it exceeds the working limit, such as over 75 ??, it will automatically turn off the power to secure the safety of both the operator and device.

5.[3 Years Warranty]: For damage caused by non-human factors, we promise to resend parts for free within 3 years. For any needs, you are warmly welcomed to contact us and we will get back to you ASAP within 24 hours.

Caution??

1.When you use this AUTOOL SDT 202 Car Smoke Leak Detector for the first time, fill with 10-20ml oil.Please be careful NOT to beyond this range.

2.The testing liquid : both liquid paraffin and baby oil are OK.

3.Fresh oil can be filled with only when the smoke gets thin, and it can??t be filled over 20ml each time.

4.Before filling fresh oil, please pour out the left oil in the detector & replace the detector oil regularly.

5. During the process of leak detection, please keep away from smoke-sensitive parts.

6. Do NOT run the detector over 8 minutes continuously. It needs interval rest.

7. The detector has an intelligent protector, if it exceeds the working limit, such as over 75 ??, it will automatically turn off the power. In this case, please operate it later.

8.The round part of this detector has temperature, please be careful to avoid burns.

9. If the test pipe needs to be disconnected in the middle, please secure the other side with a rubber stopple.

ABOUT SDT202 Packing List??

1pc * AUTOOL SDT 202 Car Smoke Leak Detector Main Unit

1pc * Hook (with hand-tighten nuts)

1pc * Rubber Connect Parts

1sets * Hard Rubber Hose Plug (with serial specification)

1pc * Standard Cone Adapter

1pc * Universal Airbag Adapter

1pc * Power Cord Clamp

1pc * Valve Core Wrench

1pc * Test Oil Refill Bottle(oil not included)

1pc * EVAP Special Connector

1pc * Smoke Hose

1pc * User Manual

ABOUT SDT206 Packing List??

1pc * AUTOOL SDT 206 Car Smoke Leak Detector Main Unit

1pc * Hook (with hand-tighten nuts)

1pc * Rubber Connect Parts

1sets * Hard Rubber Hose Plug (with serial specification)

1sets * Soft Rubber Hose Plug (with serial specification)

1pc * Standard Cone Adapter

1pc * Universal Airbag Adapter

1pc * Power Cord Clamp

1pc * Valve Core Wrench

1pc * Test Oil Refill Bottle(oil not included)

1pc * EVAP Special Connector

1pc * Smoke Hose

1pc * User Manual

Weight 4.5 kg
Ship From

China, Germany, Russia, United States
