AUTOBOSSautoboss.com
Source: https://autoboss.com/product/fxtul-m4-duc-advanced-diagnostic-tool-for-ducati-motorcycles/
0

Reviews·18

4.8 / 5Based on 18 reviews
2 ★0%
1 ★0%
Xaviera L.

This is my newly purchased M4. The packaging is intact, and the texture is good.

RandolphI

The product has a very good texture, and I like its button design.
It works very well, and I will continue to buy this product.

Tommi S.

Works good on my Ducati Monster 1100 EVO

Specifications

BrandFXTUL
Weight1800 g
Applicable ModelsDucati 749 to 1299 series, Diavel, Monster, Multistrada, Panigale, etc.
Supported ECMsBosch, Melco, several Magneti Marelli, Continental M3D/M4C/M4D/M3C
Supported SystemsECM, ABS (Bosch 5M to 9.1MP), IMU, instrument cluster, BCM, SSP, IMMO, D-AIR, radar, LED headlight
Diagnostic FunctionsModule info, read/clear codes, live data, freeze frame, actuator control (fuel pump, ignition coils, injectors, fan, etc.)
Service FunctionsService light reset, adaptation reset, TPS reset, throttle reset, ABS bleeding
Software UpdatesFree lifetime updates, one-time purchase for permanent use
Vehicle CoverageDucati motorcycles, auto-identifies model after connection

Details

Reset Service Lights and Diagnose Ducati Motorcycles

The FXTUL M4-DUC is dedicated to Ducati. It identifies the bike when connected, then reads codes, tests actuators and resets the service light and oil maintenance reminder on models from the 749 and 996 to the Panigale, Multistrada and XDiavel.

  • Ducati Only
  • Auto Model ID
  • Actuator Control
  • ABS Bleeding
  • One-Time Purchase

Key Features

  1. Wide ECM Coverage

    Works with Bosch, Melco, Magneti Marelli IAW 5AM, 5SM, 59M, 15M and 7SM, Continental M3D, M4C and M4D, and Continental Siemens M3C engine units.

  2. More Than Engine and ABS

    Also reaches the Bosch IMU, instrument clusters from several suppliers, BCM, suspension, traction system, immobilizer, D-AIR, Bluetooth, E-Lock, front and rear radar and LED headlamp.

  3. Twin-Cylinder Actuator Tests

    Control horizontal and vertical ignition coils and injectors individually, plus the fuel pump relay, electric fan, oxygen probe heater, stepper and RPM counter.

  4. Service Resets

    Switch off the service light, zero self-adaptive parameters, reset the TPS and throttle, and bleed the ABS.

  5. Fault Analysis

    Reads module information, fault codes, live data and freeze frame data recorded when a fault occurred.

M4-DUC vs Other M4 Versions

M4-DUC M4-BMW M4-HD M4-EU / M4-Asia
Brand coverage Ducati BMW Harley-Davidson 10 brands each
Connecting cables 5 4 5 10
Screen 2.8-inch 2.8-inch 2.8-inch 2.8-inch

How to Use

  1. ConnectPlug the M4-DUC into the Ducati diagnostic socket using the matching cable.
  2. Let it identifyThe tool recognizes the motorcycle after connection.
  3. Scan systemsRun Quick Test for a full fault report, or open a single unit through Control Unit.
  4. Service or testChoose a reset, ABS bleeding or actuator test and follow the on-screen steps.

Full menu walkthrough: FXTUL M4 user manual (PDF)

Updates & Support

Software updates
Free lifetime updates; one-time purchase for permanent use
Update package
Dedicated M4 Ducati package
Update method
Connect to a computer by USB, replace the DIAGNOSE folder on the new drive with the downloaded one, then power on again

Good to Know

Caution
  • Supported systems and functions depend on the equipment installed on each motorcycle. Check your bike's configuration before ordering.
  • The USB port runs on 5V and is meant only for updating from a computer; a fast charger above 5V can damage the tool.

You may also like

Select specifications

Offers

  • 10%
    10% off AUTOOL & MRCARTOOLBrands: AUTOOL, MRCARTOOL, FXTUL, CMTOOL, DUOYI · United States, United Kingdom and Australia only. Cannot be combined with other coupons.Code: AB10OFF

Offers are applied at checkout according to the store rules.

More

Delivery

Ships in 1-3 business days

Payment methods

  • Credit / Debit CardVisaMastercardAmerican Express
  • PayPalPayPal
  • Apple PayApple Pay
  • Google PayGoogle Pay
  • LinkLink
  • iDEAL | WeroiDEAL | Wero
  • BancontactBancontact
  • EPSEPS
  • Przelewy24Przelewy24
  • BancontactBancontact
  • BlikBlik
  • EPSEPS
  • iDealiDeal
  • MyBankMyBank
  • Przelewy24Przelewy24
  • TrustlyTrustly
  • MultibancoMultibanco

Available methods may vary by currency and billing country; the final list is shown at checkout.

Service

  • Secure checkout

    Payments are processed over an encrypted connection.

  • After-sales support

    Contact us for installation or usage questions.

Specifications

Brand
FXTUL
Weight
1800 g
Applicable Models
Ducati 749 to 1299 series, Diavel, Monster, Multistrada, Panigale, etc.
Supported ECMs
Bosch, Melco, several Magneti Marelli, Continental M3D/M4C/M4D/M3C
Supported Systems
ECM, ABS (Bosch 5M to 9.1MP), IMU, instrument cluster, BCM, SSP, IMMO, D-AIR, radar, LED headlight
Diagnostic Functions
Module info, read/clear codes, live data, freeze frame, actuator control (fuel pump, ignition coils, injectors, fan, etc.)
Service Functions
Service light reset, adaptation reset, TPS reset, throttle reset, ABS bleeding
Software Updates
Free lifetime updates, one-time purchase for permanent use
Vehicle Coverage
Ducati motorcycles, auto-identifies model after connection

Reviews18

4.8 / 5Based on 18 reviews
2 ★0
1 ★0
Xaviera L.

This is my newly purchased M4. The packaging is intact, and the texture is good.

RandolphI

The product has a very good texture, and I like its button design.
It works very well, and I will continue to buy this product.

Tommi S.

Works good on my Ducati Monster 1100 EVO

TRS666

Works good on my 2012 Ducati Monster 1100 EVO

Khaled A.

This Ducati diagnostic tool manually resets the maintenance reminder light! Very convenient, I recommend more riders to buy it

Rick

I have a 2020 Ducati Panigale V2… I needed to reset the maintenance and service lights and to my surprise this tool actually worked!

Arthur C.

Prompt delivery. Works like a charm.Nicely packaged kit. Lots of YouTube “how tos” if you can’t find what you’re looking for. Cleared my map sensor fault (no more engine light) and desmo service reminder on my ‘13 MTS.

Randy B.

I bought the tool to reset codes and service interval light, it will rest codes but it doesn't have the service maintenance option which is very disappointing. They need to update the software so it performs this function on my 2025 ducati scrambler 800.

Salvatore

I was looking for a tool that was Ducati specific that can diagnose and reset service reminders. This unit exceeding my expectations. Was able to quickly identify my Ducati Monster 797 and reset the annual service reminder. It also provides options to reset oil and Desmo service. Extremely please and great price for what its capable of.

Jeff

Friends, what can you expect from a $100 product? — In fact, it not only resets my motorcycle lights and bleeds the ABS system, but also comes with free lifetime upgrades!
I'm already looking forward to the next upgrade. What a great product!

Write a review

FXTUL M4-DUC Ducati Motorcycle Diagnostic Scan Tool with Actuator Test & Service Reset
Overall rating *
What stood out?optional, up to 3
Add photos0 / 5
JPG, PNG or WebP, up to 5 MB each.

Reviews are checked before they appear. Verified Purchase is added automatically when your email matches an order.
FXTUL M4-Duc – Advanced Diagnostic Tool for Ducati Motorcycles
FXTUL M4-DUC Ducati Motorcycle Diagnostic Scan Tool with Actuator Test & Service Reset

Original price was: US$245.00.Current price is: US$199.00.

Add to cart
