Blast and Recover Intake Carbon in One Workflow
HTS518 is designed to remove carbon deposits from engine intake ports and the backs of intake valves. It comes with 23 adapters, features a rated power of 1400 W and a 30 L media tank, and uses walnut shell granules sized 0.6–1.2 mm. Walnut blasting media and an external air compressor are required but not included. The machine is not suitable for cleaning fuel injectors, throttle bodies, cylinders, or combustion chambers.
- 23 Intake Adapters
- Rated power 1400W
- Capacity 30 L
- Integrated Vacuum Recovery
- Built-In Dust Filter
Key Features
-
Cleaning with Recovery
External air drives the walnut media while the integrated vacuum path collects carbon and spent media.
-
Adapters for Varied Port Shapes
Choose the adapter profile for the port, then confirm fit and seal on the exact engine.
-
Filtration and Media Reuse
The filter separates recovered media from carbon residue. Product guidance gives 5–10 uses as a reference when the media stays dry, unclumped and uncontaminated.
-
Selectable Modes
High/low and low-speed modes, used according to the HTS518 manual.
-
Mobile Storage Layout
A rear storage box, three-section telescoping handle and 360° casters keep adapters with the unit between bays.
Model Comparison
| HTS559 | HTS518 | HTS678 | |
|---|---|---|---|
| Main unit capacity | 30 L | 30 L | 10 L |
| Configured connectors | 5 types | 23 types | 23 types |
| Storage box / telescoping handle | No / No | Yes / Yes | Yes / Yes |
| Pressure gauge and regulation | No | No | Yes |
| HEPA filter | No | No | Yes |
| Weight | 12 kg | 23.5 kg | 52 kg |
What’s in the Box
- HTS518 main unit with integrated recovery
- 23 intake adapters
- Walnut blasting gun
- Black pipe adapters
- Flexible recovery hose
- Protective goggles

How to Use
- Load mediaAdd the manual-specified amount of dry walnut-shell media.
- Connect gun and hoseSecure the blasting gun and keep its nozzle within the recovery path.
- Prepare the portClose the target intake valve and isolate other openings as the vehicle procedure requires.
- Connect air and powerUse a dry, filtered compressor and the correct grounded power version.
- Blast and recoverClean one port at a time; blasting takes about 1–3 minutes per port depending on buildup.
- Recover and inspectVacuum remaining media, then inspect with good lighting or a borescope until none is visible.
- Reassemble and verifyRefit parts and complete leak checks and diagnostic and functional checks.
Adapter selection, compressor setup and maintenance: HTS518 user manual (PDF)
Good to Know
Caution
- Requires an external compressor with stable, dry, filtered air and enough continuous airflow; tank size or peak pressure alone is not enough.
- Never blast a port until its intake valve is fully closed and other openings are isolated.
- The adapters are not universal; confirm engine, port geometry and seal.
- Recover and inspect all residual media before startup rather than relying on the engine to clear it.
- Walnut-shell dust may trigger allergies; wear eye and respiratory protection, ventilate and follow the media SDS.
Care
- Clean based on inspection or diagnosis, not a fixed mileage interval; results in power or fuel economy are not guaranteed.
