Steer a 6.25 mm Camera in Any Direction Inside Engines and Pipes
The N180 is an articulating borescope with a 6.25 mm probe that bends four ways through 360°, a detachable 5-inch screen and an Android phone connection option. It is available alone or bundled with an AUTOOL HTS558 walnut blasting machine. Apple iOS connection is not supported.
- Four-Way 360° Articulation
- Detachable 5-Inch Screen
- Android Phone Link
- 8X Zoom
- IP67 Probe
Key Features
-
360° Four-Way Articulation
The probe bends up, down, left and right to reach areas such as the evaporator, combustion chamber and catalytic converter.
-
Screen or Phone
The screen and handle separate, so the handle can carry the screen or a phone holder for an Android phone.
-
Adjustable Phone Holder
The holder adjusts from 5.8 to 10.5 cm (2.2 to 4.1 in) to fit phones of different sizes.
-
One-Button Capture
A trigger on the handle takes photos and records video with one hand.
-
Large Photo and Video Storage
The memory card holds up to 10,000 photos and over 50 five-minute videos.
-
Two Power Options
Charge through Type-C or swap in a replacement lithium battery.
-
Over-Temperature Alarm
The lens sensor sounds an alarm and shows a warning when it gets too hot; the image resumes once the temperature drops.
-
Wear-Resistant Hose
The flexible hose resists abrasion for long-term use in oily, humid and dusty work.
Highlights
Detachable Screen
Use the built-in screen or mount an Android phone.
Zoom In on Detail
Enlarge the live image to inspect small parts.
Six LEDs, Three Levels
Match the light to the space you are inspecting.
More Specifications
| Camera resolution | 1 million pixels |
|---|---|
| Storage modes | Photo and video |
| Recommended operating environment | -10°C to 50°C |
| Product size | 137 × 111 × 281 mm |
Model Comparison
| N100 | N130 | N150 | N180 | N220 | |
|---|---|---|---|---|---|
| Steering | Two-way 210° | Two-way 210° | Two-way 210° | Four-way 360° | Two-way 210° |
| Display | 2.8-inch | 3.5-inch | 3.5-inch | 5-inch | 3.5-inch |
| Lens diameter | 6.25 mm | 5.5 mm | 6.2 mm | 6.25 mm | 3.9 mm |
| Depth of field | 15–100 mm | 15–100 mm | 20–100 mm | 15–100 mm | 15–100 mm |
| Magnification | 4X | 4X | 4X | 8X | 4X |
| Battery | 2600mAh | 2000mAh | 2200mAh | 2600mAh | 2000mAh |
| Detachable screen, phone connection | No | No | No | Yes | Yes |
| External monitor | Yes | Yes | No | Yes | Yes |
What’s in the Box
- N180 main unit
- Storage bag
- User manual
- Phone holder
- Handle-to-screen cable
- Phone connection data cable
- Data cable
- Wiper cloth
- Card reader
The N180 + HTS558 bundle also includes the AUTOOL HTS558 walnut blasting machine. Setup and operation: N180 user manual (PDF).
Good to Know
Caution
- Wait 1–2 hours for the engine to cool before testing; high temperatures can damage the camera.
- The screen is not waterproof. Keep liquids such as engine oil out of the screen; liquid entering it will damage the screen.
- Apple iOS phones are not supported. If the light flashes on a connected phone, the phone’s processor version is too low; use the built-in screen instead.
Care
- Make sure the screen is properly connected to the charger, or it will not charge. Charging from a computer is recommended over phone chargers, as overloading may shorten battery life.
