Reviews·61

4.9 / 5Based on 61 reviews
3 ★0%
2 ★0%
1 ★0%
#schenk24

Great for clearing codes

I have a newer car with a few electrical problems. So far I am using this just to clear the codes and the check engine lights after some battery issues so I haven't quite used all of the features yet. To be honest, this has so many things to do I really need to look over the manual so I don't mess something up in my engine. I'm not super thrilled that you need to connect wifi and an account but I know it's pretty essential for updates and such. Ive used a cheap obd computer and the cords always seem so short. This computer has long cords so you can sit comfortably and not have to be under the dash.

Albert Q.

Great 😊

Incredible automotive scanner; fast and with coverage for many brands. The two-way control is real and makes everything easy. Great purchase!

Monica J.

Paid itself with key programming alone

This tool has been a great addition to my garage, and has already paid for itself over a couple of months.The unit is fairly intuitive, and reads the information easily and quickly.I've used it to read raw data to troubleshoot issues that don't throw out a code.We recently got a used 2016 4Runner with only one key, and discovered that this tool can program transponder keys, saving us almost $500 vs. the dealer.I don't know if I will re-subscribe after the initial subscription ends - I've heard you don't need to renew, you just won't get updates.I've used it on a 2023 Porsche Macan, 2003 Tacoma, 2014 Civic,2016 4Runner and 2025 Tacoma with no issues.

Specifications

BrandAUTEL
Weight788 g
Operating SystemAndroid 11
Processor / MemoryRockchip RK3566 (Cortex-A55 1.8GHz), 4GB + 64GB
Display7-inch capacitive touchscreen 1024x600
Battery3.7 V/5000 mAh, approx. 7 hours
ConnectivityUSB wired; dual-band Wi-Fi 2.4 & 5 GHz
Diagnostic FunctionsAll-system read/clear codes, live data, bidirectional control, coding and adaptation
Service Functions28+
Vehicle Coverage80+ brands (1996 and newer)
Operating Temperature-10°C to 60°C
Dimensions / Weight270.8 × 176.0 × 36.0 mm, 885g
Free Updates1 year
Compatibility80+ global makes 1996 and newer; FCA AutoAuth requires latest software
Software Updates1-year free updates, multi-language

Details

All-System Diagnostics, Active Tests and 28+ Service Functions on a 7-Inch Tablet

The MaxiCOM MK808Z reads and clears codes, shows live data and retrieves ECU information on all available systems, and adds bi-directional active tests, coding and adaptations and a wide menu of service resets. FCA AutoAuth access is unlocked with the latest software update.

  • All-System Diagnostics
  • Bi-Directional Control
  • Coding & Adaptations
  • AutoVIN
  • FCA AutoAuth

Key Features

  1. OE-Level Diagnostics

    Read and erase codes on all available systems, view freeze frame and ECU information, and display live data as text, graph or analog; diagnosis reports help reveal the cause of a problem.

  2. Bi-Directional Active Tests

    Send commands to the ECU to activate and monitor actuators such as ABS, windows, doors, solenoids, valves and wipers, to find bad parts quickly.

  3. Service Functions

    Oil reset, EPB service, ABS auto bleed, SAS calibration, DPF regeneration, injector reset and service interval reset.

  4. Coding and Adaptations

    Perform coding and adaptations on supported modules.

  5. AutoVIN

    Automatically identifies the vehicle make, model and year.

  6. FCA AutoAuth

    With the latest software update, securely serves modern FCA vehicles for OBDII diagnostics and active tests.

  7. Videoscope Compatible

    Works with a compatible videoscope.

More Specifications

Ports Mini USB 2.0, USB 2.0, HDMI Type A, Micro SD card slot (up to 32GB)
Sensors Light sensor for automatic brightness
Audio output Beep
Battery type Lithium-polymer
Charging 5 VDC power supply; 5V/1.5A charging input
Power consumption 600 mA at 3.7 V (LCD on at default brightness, Wi-Fi on)
Storage temperature -20°C to 70°C (-4°F to 158°F)
Operating humidity 5%–95% non-condensing
Protocols ISO 9141-2, ISO 14230-2, ISO 15765, K/L-Line, Flashing Code, SAE J1850 VPW, SAE J1850 PWM, ISO 11898 (high, middle, low speed and single-wire CAN, fault-tolerant CAN), SAE J2610, GM UART, UART Echo Byte, Honda Diag-H, TP 2.0, TP 1.6

What’s in the Box

  • 1×MK808Z main unit
  • 1×USB external power adapter
  • 1×USB cable (for testing)
  • 1×USB cable (for charging)
  • 1×Quick reference guide
  • 1×User manual
  • 1×Carrying case

You may also like

Select specifications

Delivery

Ships in 1-3 business days

Payment methods

  • Credit / Debit CardVisaMastercardAmerican Express
  • PayPalPayPal
  • Apple PayApple Pay
  • Google PayGoogle Pay
  • LinkLink
  • iDEAL | WeroiDEAL | Wero
  • BancontactBancontact
  • EPSEPS
  • Przelewy24Przelewy24
  • BancontactBancontact
  • BlikBlik
  • EPSEPS
  • iDealiDeal
  • MyBankMyBank
  • Przelewy24Przelewy24
  • TrustlyTrustly
  • MultibancoMultibanco

Available methods may vary by currency and billing country; the final list is shown at checkout.

Service

  • Secure checkout

    Payments are processed over an encrypted connection.

  • After-sales support

    Contact us for installation or usage questions.

Specifications

Brand
AUTEL
Weight
788 g
Operating System
Android 11
Processor / Memory
Rockchip RK3566 (Cortex-A55 1.8GHz), 4GB + 64GB
Display
7-inch capacitive touchscreen 1024x600
Battery
3.7 V/5000 mAh, approx. 7 hours
Connectivity
USB wired; dual-band Wi-Fi 2.4 & 5 GHz
Diagnostic Functions
All-system read/clear codes, live data, bidirectional control, coding and adaptation
Service Functions
28+
Vehicle Coverage
80+ brands (1996 and newer)
Operating Temperature
-10°C to 60°C
Dimensions / Weight
270.8 × 176.0 × 36.0 mm, 885g
Free Updates
1 year
Compatibility
80+ global makes 1996 and newer; FCA AutoAuth requires latest software
Software Updates
1-year free updates, multi-language

Reviews61

4.9 / 5Based on 61 reviews
3 ★0
2 ★0
1 ★0
#schenk24

Great for clearing codes

I have a newer car with a few electrical problems. So far I am using this just to clear the codes and the check engine lights after some battery issues so I haven't quite used all of the features yet. To be honest, this has so many things to do I really need to look over the manual so I don't mess something up in my engine. I'm not super thrilled that you need to connect wifi and an account but I know it's pretty essential for updates and such. Ive used a cheap obd computer and the cords always seem so short. This computer has long cords so you can sit comfortably and not have to be under the dash.

Albert Q.

Great 😊

Incredible automotive scanner; fast and with coverage for many brands. The two-way control is real and makes everything easy. Great purchase!

Monica J.

Paid itself with key programming alone

This tool has been a great addition to my garage, and has already paid for itself over a couple of months.The unit is fairly intuitive, and reads the information easily and quickly.I've used it to read raw data to troubleshoot issues that don't throw out a code.We recently got a used 2016 4Runner with only one key, and discovered that this tool can program transponder keys, saving us almost $500 vs. the dealer.I don't know if I will re-subscribe after the initial subscription ends - I've heard you don't need to renew, you just won't get updates.I've used it on a 2023 Porsche Macan, 2003 Tacoma, 2014 Civic,2016 4Runner and 2025 Tacoma with no issues.

Partha G.

Effortless experience

In one word, it's "fantastic". Must-own device/tool for DIY work.

Robert C.

The tablet is great

The tablet is great, the only weird thing is it keeps saying i need VCI for certain stuff when the tablet has a wired connection and no option for VCI.

Joey B.

This thing is great

This thing is great. It has already saved me a couple times.

Umar C.

Recommend

It’s a really helpful device for your car. It’s shows all major electrical issues in the car

Saeed

Already Paying for Itself

I’ve only had this scanner a short time and it’s already helping me make my money back. It’s super easy to use, fast, and works on a wide range of vehicles which is perfect for what I need. The active tests and service functions give me way more control when diagnosing issues. It feels like a professional tool but still simple enough to learn quickly. Definitely a great investment if you’re doing your own work or starting out.

Derek W.

Great scanner for the price

Transaction was smooth, shipping was quick. For a lower end scanner it is actually pretty capable and quick.

S. D.

Capable unit

As a DIYer who mostly sticks to mechanical repairs like brakes, suspension, spark plugs, alternator, etc. on my Toyotas, I haven't needed intense electrical diagnostics yet, but with my cars getting older, I wanted something robust. This Autel should definitely get the job done.The hardware itself feels like a relic in some ways, particularly the use of a Mini-USB B charging port. It feels like this casing hasn't been updated in twenty years, and as someone trying to consolidate everything to USB-C, being forced back to a connector that predates even Micro-USB is a major annoyance.The setup was easy enough but took an eternity because of the sheer volume of updates required out of the box. Once you get past that hurdle, the performance is a mixed bag. While the live data streams are very responsive and fast, the actual interface feels like a computer from 2006. Navigating menus and connecting to the vehicle involves a lot of waiting for screens to load, which feels clunky compared to a modern smartphone. However, since I haven't used other scanners, this might actually be considered quick for the industry.On the bright side, the screen is decent and the body is rugged and grippy enough to survive being dropped in a garage. Trying to decipher the Autel product lineup is an absolute nightmare because of how confusing the differences between models are, but the hardware and software are undeniably reliable. If you can actually figure out which version you need, you will likely be happy with the purchase.
